The DD8-SV2 is a super solid power supply for small to medium sized pedal boards requiring reliable power for up to 8 pedals. The switchable output voltage on connections 7 and 8 allow for more flexible combinations of pedals without needing to run different supplies to the same board. The whole thing is fully isolated too, meaning no electrical noise is added from the power supply.
Comes with all the cables you'll need to set up your board, as well as cable management and hook-and-loop to secure the unit.
Input: 12V 3A
Output 1-6: 9V 500mA
Output 7-8: 9V/12V/18V 500mA Adjustable
| Size |
140*70*30mm |
| Weight |
200g |
| Package size |
273 x 236 x 64 mm |
| Package weight |
1333g |
| Input |
12V3A |
| Output power |
27W(MAX) |
| Output channels |
8 |
| Outputs 1-6 |
9V500mA |
| Outputs 7-8 |
9V/12V/18V 500mA |
Short/overload protection |
YES |
| Isolated |
FULLY ISOLATED |
| |
|
